The control panel sends alarms and signals to the centre using the IDP, ADF, or C200b protocols. The only certified protocol is IDP.
Control panel with a programmable bus to control the system, capable of managing signals
relative to intrusion, sabotage, and technological events separately.
The control panel is equipped with:
4 inputs;
1 balanced SAB input;
2 outputs (1 relay output and 1 electric output);
1 switching power supply to provide power to internal circuits and devices;
internal seating for battery;
internal seating for 4 expansions.
The control panel manages up to 4 distinct partitions.
Other characteristics of the control panel are:
protection against opening and removal;
saving of the last 1000 events;
management of a timing programmer.
The power supply of all the internal circuits and devices is provided by a 230 V~ - 14,4 V⎓ - 1,5 A
switching power supply; the use of a 12 V, 7.2 Ah battery backup is also provided.
The programming is carried out with a keypad through a simple tree menu available in 10
languages.
Otherwise, for greater convenience, the system can be programmed with a local PC, connected to
the control panel via the IT-USB/KEY interface and with Hi-Connect software installed (revision
3.60 or later). The programming can be saved on a USB pen drive.
The functional capacities of the MP500/4N control panel can be increased with optional devices.
EN50131 Certification: Grade 2 - Class II
