8.9 DK510M-P PROXIMITY READER
Nominal power voltage
13.8 V⎓ (taken from bus)
Reader operating voltage
9 V⎓ to 15 V⎓
Nominal current absorbed at 12 V⎓
40 mA in stand-by
68 mA max (with all LEDs ON)
Max total length of control panel-peripheral serial Bus line
400 m
Max length of the connection between each sensor and the reader
500 m
Max length of the connection between a fast sensor (roller, shock,
...) and the reader
100 m
Type of communication
Elkron serial protocol
Auxiliary inputs
2
Certified operating temperature
(EN50131 – Environmental class II, internal general)
-10°C ÷ +40°C
Average relative humidity during operation
75%
Storage temperature
-20°C ÷ +60°C
Degree of protection of casing
IP40 / IK06
8.10 8-INPUT EP508 EXPANSION MODULE
Nominal power voltage
13.8 V⎓ (taken from bus)
Expansion operating voltage
9 V⎓ to 15 V⎓
Nominal current absorbed at 12 V⎓
35 mA stand-by (with energised relay, default condition)
22 mA max. with relay de-energised
Nominal voltage on the +V1 terminal
13.2 V⎓
Max current deliverable from +V1 terminal
500 mA
Nominal voltage on the +V2 terminal
13.2 V⎓
Max total current deliverable from the +V2 terminals
500 mA
Max current and voltage of relay contact switch of outputs U1
1 A – 24 V⎓ with resistive load
Max current deliverable from electric outputs U2 and U3
10 mA
Max total length of control panel-peripheral serial Bus line
400 m
Max. connection length between each sensor and the expansion
500 m
Max length of the connection between a fast sensor (roller, shock,
...) and the expansion
100 m
Type of communication
Elkron serial protocol
Certified operating temperature
(EN50131 – Environmental class II, internal general)
-10°C to +40°C
Average relative humidity during operation
75%
Storage temperature
-20°C to +60°C
8.11 VOCAL SYNTHESIS BOARD SV500N-I-F-GB
Nominal power voltage
13.8 V⎓ (taken from the control panel)
Operating voltage of the vocal synthesis board
10.5 V⎓ to 15 V⎓
Nominal current absorbed at 12 V⎓
3 mA in stand-by
20 mA max. (during message reproduction)
Max length of the audio line (audio bus)
300 m with twin telephone line
Max number of messages that can be recorded
94
8.12 ILT500-N PSTN COMMUNICATOR
Nominal power voltage
13.8 V⎓ (taken from the control panel)
Nominal current absorbed at 12 V⎓
3 mA in stand-by
20 mA max. (during telephone connection)
Reference legislation
EN50136-2
ATS classification
SP2
Operating mode
Pass-Through
