1.2.3 Maximum system size
Table 1 illustrates the maximum number of keypads, readers, keys and expansion modules that can comprise the MP500/xx systems.
For each device, the maximum individuals and combinations are indicated when the system comprises similar devices.
For example, the table makes it possible to deduce that the maximum number of readers that can be installed is 32, regardless if just
one type or both types in the desired combination are used.
Device
MP500/4N System
MP500/8 System
MP500/16 System
Max
Number
of each
type
Max Number
of mixed
combination
Max
Number
of each
type
Max Number
of mixed
combination
Max
Number
of each
type
Max Number
of mixed
combination
KP500D/N
Command keypad
4
4**
8
8**
8
8**
KP500DV/N
Vocal command keypad
4
8
8
KP500DP/N - KP500D/ST
Touch Screen
4
8
8
EP508 Expansion module
3
3 (§)
7
7 (§)
15
15 (§)
Radio expansion
1
2
2
AS500/RPT supplemental
power supply with repeater
-
7
15
DK500M-E
Electronic key reader
4
4
16
16
16
16
DK500M-P/DK510M-P
Transponder reader
4
16
16
DK50 Electronic key
16
16
32
32
64
64
DK30/DK70 Proximity key
16
32
64
Access Code*
16
-
32
-
64
-
* of which 1 Master, 1 Technician and 1 Technical Manager.
** by using the Service keypad, the max number is decreased by one unit: it becomes 3 in the MP500/4N control panel, 7 in the
MP500/8 and MP500/16 control panels.
§ - WARNING! The maximum number of the mixed combination must take into account the number of radio expansions.
Table 1 - Maximum system dimension MP500/4N, MP500/8 and MP500/16
Table 2 illustrates the maximum number of wired inputs and outputs that a system can reach at its maximum expansion.
Type
MP500/4N System
MP500/8 System
MP500/16 System
Max Number
Max Number
Max Number
Inputs for general use
32
64
128
Tamper inputs (SAB)
4
8
16
Relay outputs
4
9
17
Electrical outputs
7
18
34
Table 2 - Max number of wired inputs and outputs
1.3 SYSTEM CONNECTIVITY
The MP500/4N, MP500/8, and MP500/16 systems can be connected to the external environment in different ways, sending signals and
receiving commands.
Possible connection methods are:
 Public Switched Telephone Network (PSTN). Requires ILT500-N interface (standard in MP500/8 and MP500/16 control
panels).
 Mobile network (GSM). Requires optional IMG500/N interface.
 USB. Requires optional IT-USB/KEY interface.
 Web Server: Requires optional IT500WEB interface.
The vocal function requires an optional SV500N.
