MP500/4N-8-16 Installation
8.6 KEYPAD TOUCH SCREEN KP500D/ST
Nominal power voltage
13.8 V⎓ (taken from bus)
Keypad operating voltage
10 V⎓ to 15 V⎓
Nominal current absorbed at 12 V⎓
32 mA (in stand-by, only LED for presence mains supply)
68 mA (average absorption with backlighting at level 1)
110 mA (average absorption with backlighting at level 4)
200 mA (maximum peak absorption)
Max total length of control panel-peripheral serial Bus line
400 m
Type of communication
Elkron serial protocol
Type of memory for program maintenance
Data Flash
Type of memory for vocabulary maintenance
Data Flash
Certified operating temperature
(EN50131 – Environmental class II, internal general)
-10°C to +40°C
Average relative humidity during operation
75%
Storage temperature
-20°C to +60°C
Degree of protection of casing
IP40 / IK06
Weight
460 g
Dimensions (W x H x D)
160 x 130 x 23.5 mm
8.7 DK500M-E ELECTRONIC KEY READER
Nominal power voltage
13.8 V⎓ (taken from bus)
Reader operating voltage
9 V⎓ to 15 V⎓
Nominal current absorbed at 12 V⎓
6 mA in stand-by
56 mA max (with all LEDs on)
Max total length of control panel-peripheral serial Bus line
400 m
Max length of the connection between each sensor and the reader
500 m
Max length of the connection between a fast sensor (roller, shock,
...) and the reader
100 m
Type of communication
Elkron serial protocol
Auxiliary inputs
2
Certified operating temperature
(EN50131 – Environmental class II, internal general)
-10°C to +40°C
Average relative humidity during operation
75%
Storage temperature
-20°C to +60°C
Degree of protection of casing
IP40 / IK06
8.8 DK500M-P PROXIMITY READER
Nominal power voltage
13.8 V⎓ (taken from bus)
Reader operating voltage
9 V⎓ to 15 V⎓
Nominal current absorbed at 12 V⎓
40 mA in stand-by
68 mA max (with all LEDs ON)
Max total length of control panel-peripheral serial Bus line
400 m
Max length of the connection between each sensor and the reader
500 m
Max length of the connection between a fast sensor (roller, shock,
...) and the reader
100 m
Type of communication
Elkron serial protocol
Auxiliary inputs
2
Certified operating temperature
(EN50131 – Environmental class II, internal general)
-10°C to +40°C
Average relative humidity during operation
75%
Storage temperature
-20°C to +60°C
Degree of protection of casing
IP40 / IK06
