4) Example of connection with alarm on roller input
5) Example of connection on double BAL input
6) Example of connection with alarm and ta
mper on double BAL input BAL
7) Example of connection with tamper and anti
-foam module on double BAL input.
IMPORTANT!
Each sensor must be powered by the device that controls it. The balancing resistors must be connected to the
positive
of the power supply
of the same device.
