The wiring of the Main Feedback cable depends on the type of device used. Incremental
Encoder wiring, Interpolated Analog Encoder wiring and Resolver wiring are shown in the
table below.
Incremental Encoder
Interpolated Analog
(Sine/Cosine) Encoder Resolver
Tachometer and
Potentiometer
BAS X/230_ BAS X/230I BAS XX/230R BAS XX/230T
Pin Signal Function Signal Function Signal Function Signal Function
1 HC Hall sensor C input HC Hall sensor C
input
NC - HC Hall sensor C
input
2 HB Hall sensor B input HB Hall sensor B
input
NC - HB Hall sensor B
input
3 HA Hall sensor A input HA Hall sensor A
input
NC - HA Hall sensor A
input
4 SUPRET Supply return SUPRET Supply return SUPRET Supply return SUPRET Supply return
5 SUPRET Supply return SUPRET Supply return SUPRET Supply return SUPRET Supply return
6 +5V Encoder/Hall
+5 V supply
+5V Encoder/Hall
+5 V supply
NC - +5V Encoder/Hall
+5 V supply
7 INDEX- Index complement R- Reference
complement
R2 Vref complement
f= 1/TS, 50mA
Maximum
NC -
8 INDEX Index R+ Reference R1 Vref f=1/TS, 50mA
Max.
POT Potentiometer
input
9 CHB- Channel B cmplmnt B- Cosine B
complement
S4 Cosine B complement Tac 2- Tacho Input 2
Neg. (50V max)
10 CHB Channel B B+ Cosine B S2 Cosine B Tac 2+ Tacho Input 2
Pos. (50V max)
11 CHA- Channel A cmplmnt A- Sine A
complement
S3 Sine A complement Tac 1- Tacho Input 1
Neg. (50V max)
12 CHA Channel A A+ Sine A S1 Sine A Tac 1+ Tacho Input 1
Pos. (50V max)
Table 3-4A: Main Feedback Cable Pin Assignments
