11
BASIC
OPERATIONS
2-2 Supplied accessories
Remote control
Preparation of the remote control
Remove the battery case by pressing the release lock inward.
Insert the coin battery into the battery case, so you see the positive (+) side facing
up. Then insert the battery case into the remote control.
Operation of the remote control
For operations when the camera image is displayed, refer to
P.15
For operations when data in the SD card/USB flash drive is displayed, refer to
P.33
Receiving IR signal from the remote control
Point the IR transmitter of the remote control to the IR receiver of the product,
and press the desired button.
Receivable range:
Distance: Within approx. 7m from the front of the IR receiver
Angle: Within 45° up, down, left, and right of the IR receiver
RC
-
VLH
R
C
-
V
L
H
R
C
-
V
L
H
45°
45°
45°
45
°
45°
45°
45°
45
°
45
°
• Use a commercially available CR2025 coin
battery for the remote control.
• The receivable range may be reduced when the product is
placed in direct sunlight, near an inverter uorescent light or
in any other unfavorable conditions. Depending on the light
source conditions, the sensor may fail to receive any infrared
light. In such cases, relocate the product or shield the light
source.
Note
Warning
Children may ingest small batteries. Always keep
batteries safe and out of reach of children.
If a battery is swallowed, consult a doctor immediately as this could
result in asphyxiation or be an obstacle to digestion, etc.
