12
BASIC
OPERATIONS
Fixture
How to use the supplied xture and cable tie
You can fix the HDMI cable to the HDMI port by using the supplied fixture and
cable tie.
Items to use (supplied)
①
Before connecting the HDMI cable to the HDMI port, remove the screw
above the HDMI port. Attach the xture and tighten the screw.
②
Pass the cable tie through the xture and tie it around the plug of the HDMI
cable.
Fixture
(For HDMI cable)
Cable tie x 2
Screw
Fixture
HDMI cable (plug)
• The supplied cable tie can be used repeatedly.
Concave part
Cable tie
・When the plug has a concave part, tie
the cable tie around the concave part
to get a rm hold.
