13
BASIC
OPERATIONS
When the plug does not have a concave part, wrap the cable tie as shown below.
①
Wrap the cable tie around the root of the cable and pull it tight.
②
Remove the screw above the HDMI port and connect the HDMI cable. Attach
the xture and tighten the screw.
Caution
Depending on the shape of the plug, the xture may not be used.
with concave part without concave part
Concave part
Fixture
HDMI cable
Cable tie
Screw
