16
BASIC
OPERATIONS
Adjusting the size
The display range of the document can be adjusted by rotating the zoom dial on
the product or by pressing the [ / ] buttons on the remote control.
・ZOOM-IN ：The object will be shown in large size.
・ZOOM-OUT ：The object will be shown in small size.
If you cannot get a focused image, use the AF button on the camera head or the
[ ] button on the remote control.
Zoom dial
Zoom
287
(smaller)
Zoom
,1
(larger)
AF button
• Zoom ratio: 24x (Optical zoom 12x + Sensor zoom 2x), Digital zoom 12x (Total 288x zoom)
( ※ The sensor zoom does not work when the output resolution is UHD.)
• When the optical zoom reaches 12x, it will automatically shift to the sensor zoom rst, and
then to the digital zoom.
• The digital zoom can be switched between ON and OFF from the System Setting menu.
(Image Quality Setting: Digital zoom)
• When the digital zoom is set to OFF, only the optical zoom works. (The sensor zoom does
not work.)
