ADVANCED
OPERATIONS

RS-232C specifications
Data format specifications
This command is executed in the form of 1 command / 1 packet. Until one process
is completed, the next command is not accepted.
・ The communication command always starts with STX (Start of Text)
and ends with ETX (End of Text).
・ If the communication format or command name is wrong, the unit
does not respond correctly and send NAK (Abnormal receiving:
Negative Acknowledge).
・ When the correct communication format is received, the unit sends
ACK (Normal receiving: Acknowledge).
Operation command (PC → Unit)
Each operation command is executed in ASCII code, and transmitted in a set of 7
bytes as follows:
(PC)
S
T
X
Command Parameter Data
E
T
X
(Unit) → ACK
Response data format (Unit → PC)
All response data is transmitted in ASCII code, corresponding to the parameters
in the operation command table.
・Status 0
S
T
X
Lamp
0:OFF
1:ON
Guide
0:OFF
1:ON
Posi/Nega
0:POSI
1:NEGA
Color/B&W
0:COLOR
1:B&W
Output Video
0:CAMERA
1:RGB IN
2:THUMBNAIL
20H
Pause
0:OFF
1:ON
Flickerless
0:60Hz
1:50Hz
E
T
X
・Status 2
S
T
X
Iris
1:AUTO
2:MANUAL
Gamma
0:High
1:MEDIUM
2:LOW
Image Rotation
0:OFF
1:ON
Edge Effect
1:LOW
2:MEDIUM
3:HIGH
White Balance
0:MANUAL
1:AUTO
2:ONE PUSH
Image Mode
0:GRAPHIC1
1:TEXT1
2:TEXT2
3:TEXT3
4:GRAPHIC2
Resolution
1:SXGA
2:XGA
3:720p
4:WXGA
5:1080p
USB Mode
0:
Mass Storage
1:Application
E
T
X
・Status 3
S
T
X
AF Mode
0:AUTO
1:MANUAL
2:
ZOOM SYNC
Digital Zoom
0:OFF
1:ON
Movie Quality
1:LOW
2:MEDIUM
3:HIGH
Audio Selector
1:Built in mic
2:Mic in
3:Line in
Select Memory
0:SD
1:USB
Highlight
0:OFF
1:ON
Mask
0:OFF
1:ON
Scroll
0:OFF
1:ON
E
T
X
