UART Communication format
Commands, parameters and data are all transmitted in ASCII code.
Operation Command Parameter Data Function
Power PW
0 (OFF)
■■ To turn ON/OFF the power.
1 (ON)
Auto Focus AF 0 ■■ To perform the one-shot auto focus.
Zoom Adjustment ZO
+ (TELE)
■■ To adjust the zoom.
(WIDE)
0 (STOP)
Iris Adjustment IR
+ (OPEN)
■■ To adjust the iris.
(CLOSE)
0 (STOP)
3 (NORMAL)
Lamp Switching PL
0 (OFF)
■■ To turn ON/OFF the lamp.
1 (ON)
Output Video Switching AV
0 (CAMERA)
■■ To switch the output video.1 (RGB IN)
2 (THUMBNAIL)
Direction KE
2 ( → )
■■
"To perform the same operation as the direction buttons.
(Examples)
・Select the OSD menu item
・Move the highlighted area
3 ( ← )
4 ( ↑ )
5 ( ↓ )
6 (
MENU/ENTER )
Pause FZ
0 (OFF)
■■ To pause the image.
1 (ON)
Image Saving CA 0 ■■
To save the still image on the SD card / USB flash drive.
Movie Recording RC
0
(Stop recording)
■■ To save the movie on the SD card / USB flash drive.
1
(Start recording)
Resolution RL
1 (SXGA)
■■ To switch the resolution.
2 (XGA)
3 (720p)
4 (WXGA)
5 (1080p)
Play Movie PM
0 (stop)
■■ To play/stop/cueing the movie.1 (Play)
2 (Cueing)
Audio Volume VL
+ (Up)
■■ To set the output audio volume.
(Down)
Local Lockout LL
0（OFF)
■■
To invalidate the operation of the front operating panel
and the remote control.
1（ON)
Status Request QS
0
■■ To inquire about the unit status.
2
3
4
*For “■■” in the data column, transmit the SPACE [20H] twice.
