5-2 Main Camera
Item Specifications
Lens
f = 4.9mm – 78.4mm (16x zoom) F2.7
Frame rate 30fps
Shooting area
Max. Min.
1080p
400mm x 223mm 27mm x 15mm
720p 400mm x 223mm 27mm x 15mm
SXGA 400mm x 320mm 27mm x 22mm
WXGA 400mm x 248mm 27mm x 17mm
XGA 400mm x 299mm 27mm x 20mm
Limit of focus
adjustment
With close-up lens
TELE side (Telescopic) : 250mm - 440mm from the close-up lens
WIDE side (Wide-angle) : 90mm - 440mm from the close-up lens
Without close-up lens
TELE side (Telescopic) : 500mm -
∞
from the zoom lens surface
WIDE side (Wide-angle) : 100mm -
∞
from the zoom lens surface
Optical zoom 16X
Digital zoom 8X
Focus Auto/Manual/Zoom Sync
Image pick-up element 1/2.8” CMOS
Total pixels Horizontal 2144, Vertical 1588
Effective pixels Horizontal 1920, Vertical 1536
Synchronized signal Internal
Resolution
Analog RGB Horizontal 800TV lines or more Vertical
800TV lines or more
Analog RGB output
Analog RGB output 0.7 V (p-p)
75
Ω
unbalanced
Synchronized signal
SXGA : Positive polarity
WXGA : Horizontal
negative polarity,
Vertical positive
polarity
XGA : Negative polarity
1080p : Positive polarity
720p : Positive polarity
SXGA: 1280x1024@60Hz
Horizontal frequency: 63.981kHz
Vertical frequency: 60.020Hz
WXGA: 1280x800@60Hz
Horizontal frequency: 49.306kHz
Vertical frequency: 59.910Hz
XGA: 1024x768@60Hz
Horizontal frequency: 48.363kHz
Vertical frequency: 60.004Hz
1080p: 1920x1080@60Hz
Horizontal frequency: 67.50kHz
Vertical frequency: 60.00Hz
720p: 1280x720@60Hz
Horizontal frequency: 45.00kHz
Vertical frequency: 60.00Hz
