Elmo TT-02S - Part Names and Functions; Component Identification

10
English
PART
NAMES AND
FUNCTIONS
No Name No Name
(1) Camera head (7) Stage positioning
P. 2 5
(2) Illumination lamp switch (8) Rear panel
P. 1 2
(3) Zoom dial
P. 3 5
(9) Side panel
P. 1 3
(4) AF Button
P. 3 6
(10) Magnetic sheet
P. 2 5
(5) Camera column (11) Stage
P. 2 5
(6) Operating button
P. 1 1
(12) Anti-glare sheet
P. 2 5
(11)
(10)
(12)
PART NAMES AND FUNCTIONS
(9)
(8)
(1)
(5)
(4)
(3)
(6)
(7)
(2)
Rear
Front
Name of Each Part
Appearance
1
