25
English
OPERATION
PROCEDURE
Presentation using printed materials, etc. (Using the stage)
Using the supplied stage, magnetic sheet or anti-glare sheet, effective presentation is
possible.
■ Setting the main unit
Attach the stage to the specified position as shown in the above figure and connect to the
projector or the PC monitor. Then turn the power switch of the main unit ON.
• To prevent the printed materials, etc. from moving, use the supplied magnet sheet to
properly fix the printed materials, etc. on the stage.
■ Adjusting the size
Place an object on the stage, adjusting the position of the object with the zoom dial so that
the objective part fits the screen size.
P. 3 5
■ Adjusting the focus
Press the [AF] button to focus the camera on the object.
P. 3 6
■ Adjusting the brightness
Press the [BRIGHTNESS •
] and [BRIGHTNESS • ] buttons on the main unit to
adjust image brightness.
P. 3 9
■ Turning the lamp ON/OFF
Slide the lamp switch to the left/right to turn it ON/OFF.
Note
• When shooting glossy documents, etc, the images may be hard to see due to glare,
etc. In such cases, place the anti-glare sheet, supplied, over the area where glare is
occurring. This will reduce glare and the images will become easier to see.
To Next Page
