40
English
VARIOUS
FUNCTIONS AND
OPERATIONS
Image selection
The camera image is displayed by [CAMERA] button while the input image into the analog
RGB input [RGB IN] is displayed by [PC] and the images in SD card is displayed by [SD]
button.
The camera image and the image input in the RGB input terminal [RGB IN] can be
switched by pressing the [CAMERA] button and the [PC] button respectively.
By using these functions, output images can be switched without disconnecting cables.
Note
• The [PC] button can not be used when the dip switch is set to VIDEO.
• When using a laptop PC with external output selection equipped, set the output
mode of the PC to “external” after pressing the [PC] button on the main unit.
• When the OSD is displayed, the [SD] button functions as [
(lower arrow button) ].
