NO. Part Number Name
PARTS LIST
54
MODEL 8300
Timing belt
Upper shaft (unit)
Setscrew 3x6
Hexagonal socket screw 5x4
Hexagonal socket screw 5x8
Upper shaft front bushing
Washer
Uppere shaft ring
Setscrew 4x12
Upper shaft shield plate
Washer
Setscrew 4x8
Thread take-up lever (unit)
Thread teke-up lever support pin (unit)
Thread take-up lever support pin
Snap ring 6
Hexagonal socket screw 4x4
Hexagonal socket screw 5x5
Felt
Bearing
Snap ring 5103-37
Upper shaft rear metal
Upper shaft timing gear
Spring pin 3x20
Spring pin 3x30
Clutch ring
Clutch spring
Belt wheel
Snap ring 8
Handwheel
Timing belt
Belt wheel (unit)
Upper shaft releasing cam
Cushion
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
850165003
854639201
000078319
000110901
000111706
829042007
000038605
639095000
000101703
830095010
820102009
000081005
820511201
650626001
650062003
000001702
000111201
000111304
731384008
000208505
000032609
851062002
830341003
000004303
000024206
502064003
661024007
303025009
000030205
502068007
650071005
852629109
854121009
854143007
