41
Table 4.1 Voltage and Current Messages
Phase Order Messages
Table 4.2 Phase Order Messages
Message
Voltage Current
OK
Voltage “OK” present on Lines.
If “OK” is not present on 3
Lines, then it is not connected
correctly
Current present in
Lines and synchronized
with Voltage Lines. If
“OK” is not present on
3 Lines, then it is not
connected correctly
OPP
Wired in incorrect
direction
NO
No Voltage No current
Message
Voltage
OK
Correct Phase Order of Voltage Connections
OPP
Incorrect Phase Order i.e. Line 2 does not follow Line 1
and/or Line 1 does not follow Line3
