Miscellaneous
93
8.1.7
Furnace cleaning mech
anism
Fig.
61
: Furnace cleaning
mec
hanism
Part No.
Description
14014
Complete furnace cle
aning as
sembly unit:
14021
Upper furnace lock
14045
Cleaning brush f
or com
bustion tube
14051
Brush holder
14072
Ceramic heat shiel
d for brus
h
14080
Cleaning mec
hanism Rod
14160
Upper log
70120
O-ring
75122
Spring
75130
Safety spring
75150
Metal tube
92
94
