EMAK EF 95 Workshop Manual

Workshop manual
17
Display
Fault
Fault description
Fault elimination
Err 10
Output ignition coil
Electronic system detects incorrect
status of the ignition coil output
1 Switch the ignition off and back on
(position 1)
➯ Self-diagnosis; fault can clear
automatically
*
➯Otherwise, test / replace the electronic
system
Err 11
Output internal
supply voltage
Electronic system detects incorrect
status of the internal supply voltage
output
1 Switch the ignition off and back on
(position 1)
➯ Self-diagnosis; fault can clear
automatically
*
➯ Otherwise, test / replace the electronic
system
Err 12
Output internal
supply
voltage monitoring
system
Electronic system detects
incorrect status of the internal
supply voltage monitoring system
1 Switch the ignition off and back on
(position 1)
➯ Self-diagnosis; fault can clear
automatically
*
➯ Otherwise, test / replace the electronic
system
* The display goes out for about 4 seconds in this case.
LED behaviour:
The LEDs sit on the display board.
 Open the bonnet
 Ignition in position 1.
 To see the LEDs, look from the left vehicle side of the engine compartment towards the display.
LED indicator
Fault description
Fault rectification
Only green LED is ON
Normal operation, no fault
There is no fault
Green and red LEDs are
ON
Fault during current operation
Fault rectification according to fault shown on display
Only red LED is ON
Fault during previous operation or
controller fault
Fault rectification according to fault shown on display, or
check/replace electronic system
