Workshop manual
37
In the lawn tractors without display, the relay for
electrical grass catcher emptying sits
underneaththe left wheelhouse, next to the linear
cylinder.
4.7.6 Fuses
The fuses sit underneath the control panel, next to the
starter battery.
Designation
Current in A
Cable harness (without display)
1010
Cable harness (with display)
7,5
Charge
15
Linear cylinder
10
4.7.7 Level buzzer / level switch
Remove the discharge channel to make it easier to remove the level switch.
Level buzzer
The level buzzer sit underneath the control panel, next to the starter battery.
