EMAK EF 95 Workshop Manual

Workshop manual
50
7 Torque setting
Object
Tightening
torque
Nm (± 2 Nm)
Comment
Engine
Tighten petrol engine (4x)
25
Oil drain plug
Blade brake clutch
70
Screw lock with Loctite
Transmission
25
First, tighten the transmission screws, then the screws at
the bracing.
Steering
Steering sector guide
25
Grease bearing bush.
Grease the steering sector specifically only at
the bearing surfaces and the teeth.
Steering sector pivot
65
Steering wheel fastening screw
20
Ball head M10 x 1
50
Steering-axle stub clamping lever
20
Mowing implement
Blade
65
Distance blade to lower housing edge 7 ...
max. 12 mm. Blade offset max. 3 mm
Tensioning pulley on rocker
25
Grease the bearing bush of the tensioning
pulley rocker.
The rocker must be able to move smoothly.
Mowing implement V-belt pulley
65
Guide pulleys
45
Mowing implement bearing block
25
Mowing implement suspension
rocker
45
Mowing implement adjustment
front M12
60
Propulsion
Tensioning pulley on the frame
20
