EMAK EF 95 - Lubricating Plan

Workshop manual
8
3.2 Lubricating plan
3.2.1 Front axle
WARNING!
To ensure the smooth operation of moving parts, we recommend lubricating the following
points every 50 operating hours / once a year.
 Lubricate the steering-axle stubs right and left
(lubricating nipples) with multi-purpose grease.
 Spray the front axle bearings on the frame with oil.
 Lubricate the ball heads with multi-purpose grease.
Remove the ball caps before you start lubrication
(See steering sector disassembly).
3.2.2 Steering
 Grease toothing and bearing surface of the gear
segmentwith multi-purpose grease.
 Grease the pinion.
3.2.3 Front and rear wheels
 Lubricate roller bearings / hubs with multi-
purpose grease.
Remove the front and rear wheels before you start
lubricating the axles.
Ensure that the driving key is in place when you
install the rear wheels
