Workshop manual
30
Pull out the steering column from below.
4.4.3 Replacing the tie rod
There are tie rods between the steering sector and the
front wheels, and between the front wheels.
Each side of a tie rod is connected via a ball head with
the steering-axle stub.
Remove the retaining spring behind the ball head, and
remove the tie rod.
.
Ensure that the retaining spring sits firmly when
you assemble the unit.
4.5 Propulsion
4.5.1 Removing the floor cover of the vehicle frame
To be able to remove the floor cover, remove the pedal
tops of accelerator (a+b) and brake (c) pedals.
Loosen the cheese-head screws underneath the pedal
tops.
Remove the pedal top.
