EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Removal and Replacement Procedures (RRPs)
• If the ED-DCX-4S-B is operating and will continue to operate
during the replacement, check the power LEDs to verify that
the minimum number of power supplies is functioning. A
fully populated ED-DCX-4S-B requires a minimum of one
power supply at all times.
2. Turn off the power switch.
3. Remove the power cord.
4. Loosen the thumb screw as shown in Figure 24.
5. Grasp the handle and pull, sliding the power supply from the
chassis and supporting the power supply from beneath as you
remove it.
6. If you are not replacing the power supply, insert a power supply
filler panel into the slot.
Figure 24 RRP: Power supply
