Port Numbering Template
Figure 32 Port side populated with four PB-DCX-32P port blades, two CR4S-8
blades, and two CP8 blades
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7 Slot 8
CP8 CP8
CR
4S8
CR
4S8
