EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Port Numbering Template
Figure 33 Port side populated with four PB-DCX-16P port blades, two CR4S-8
blades, and two CP8 blades
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7 Slot 8
CP8 CP8
CR
4S8
CR
4S8
