EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Port Side Exhaust Kit Installation Procedure
Install cabinet hardware
1. Determine how the ED-DCX-4S-B can be oriented in the
equipment cabinet so that the nonport side has access to intake air
(cool).
2. Install clip nuts (F in Figure 38 on page 195) or retainer nuts (G in
Figure 38 on page 195) in cabinet rail locations shown in Figure 39
on page 197. These nuts will secure the 10-32 screws that mount
the Port Side Exhaust Kit shelf and the ED-DCX-4S-B to the
cabinet. For rails with round holes, use clip nuts. For rails with
square holes, use retainer nuts. Note that Figure 39 on page 197
shows relative positions for these nuts in the cabinet rails to
mount the shelf and ED-DCX-4S-B. You may mount the shelf and
the ED-DCX-4S-B in 9 U of cabinet space higher or lower in the
cabinet than shown.
Table 27 Torque requirements for mounting screws
Screw size Torque
6-32 x .25 in. (.635 cm)
Phillips screw
8.75 in.-lbs (10 cm-kg)
10-32 x .63 in.(1.60 cm)
Phillips screw
32 in.-lbs (36.86 cm-kg)
