EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Port Side Exhaust Kit Installation Procedure
b. Secure the top-rail inner bracket to the top-rail assembly with
two 6-32 screws (K-3 inFigure 44 on page 204). Tighten screws
according to specifications under “Torque requirements” on
page 204.
7. Install the top-rail assembly:
a. Insert the top-rail assembly (with the top-rail inner bracket
attached) down into the air-duct assembly and then secure the
top-rail assembly to the air-duct assembly with two 6-32
screws, one screw on each side of the air-duct assembly (K-1
and K-2 in Figure 44 on page 204). Also refer to Figure 49 on
page 211.
b. Secure the top-rail assembly to the rack. Refer to Figure 49 on
page 211.
For rails with round holes
Use two 10-32 screws with washers (G in Figure 45 on
page 206) on each end of the top rail assembly. Tighten screws
according to specifications under “Torque requirements” on
page 204.
For rails with square holes
Use the two standard 10-32 screws (F in Figure 44 on page 204)
with blue Loctite on the threads and alignment washers (J in
Figure 44 on page 204) on each end of the top rail assembly.
Tighten screws according to specifications under “Torque
requirements” on page 204.
