Installing the ED-DCX-4S-B in Equipment Cabinet
211
Port Side Exhaust Kit Installation Procedure
Figure 49 Securing top rail in cabinet
Install ED-DCX-4S-B in cabinet
1. Ensure that the door is removed from the port side of the
ED-DCX-4S-B.
2. Use a lift to raise the chassis to the correct level.
Use safe lifting practices when moving the product. (If applicable,
lock the wheels of the lift.
3. If applicable, lock the wheels of the lift.
