VNX Block Configuration Worksheet
With your network administrator, determine the IP addresses and network parameters
you plan to use with the storage system, and record the information on the following
worksheet. You must have this information to set up and initialize the system.
You manage the storage system through a dedicated LAN port on each storage processor.
These ports must share a subnet with the host you use to initialize the system. After
initialization, any host on the same network and with a supported browser can manage
the system through the management ports.
Record network information for your system on the worksheets on the next pages. Your
network administrator should provide most of this information. For more information,
refer to your configuration planning guide.
Table 7 IPv4 Management Port Information
IP Address Subnet Mask Gateway
SP A
SP B
Do not use 128.221.1.248 through 128.221.1.255, 192.168.1.1, or 192.168.1.2 for an
IPv4 IP address.
Table 8 IPv6 Management Port Information (optional; manual configuration only)
Global prefix
Gateway
Table 9 Login information for the storage system administrator
Field Description Value
Username User choice
Password User choice
Storage-system
serial number
The serial number is located on the PSNT tag
hanging from the rear of the storage processors.
The number is identified as SN/Product ID.
Scope Global or Local
Table 10 IPv4 address for iSCSI targets
SP, slot and port Local port number Target port IP address Subnet mask Gateway
SPA, slot __, port 0
SPA, slot __, port 1
Planning Worksheets
76 EMC VNX Series VNX8000 Block Installation Guide
