150 FLOW RATE SUMMARY CHARTS
Flow rate summary charts Daniel 3410 Series Gas Ultrasonic Meter Operations Manual
January 2018 3-9000-777 Rev E
FLOW RATES (MSCMH) BASED UPON 30 M/S
kPag4 6 8 10121620243036
1000 9.67 22.01 38.11 60.07 85.27 134.6 211.7 306.2 494.5 712.1
1500 14.22 32.34 56.00 88.27 125.3 197.8 311.1 450.0 726.7 1046
2000 18.85 42.89 74.28 117.1 166.2 262.4 412.7 596.9 963.9 1388
2500 23.59 53.67 92.94 146.5 207.9 328.3 516.4 746.9 1206 1737
3000 28.43 64.68 112.0 176.5 250.6 395.6 622.3 900.0 1453 2093
3500 33.37 75.92 131.5 207.2 294.1 464.4 730.4 1056 1706 2457
4000 38.41 87.39 151.3 238.5 338.6 534.6 840.8 1216 1964 2828
4500 43.56 99.10 171.6 270.5 384.0 606.2 953.5 1379 2227 3207
5000 48.81 111.1 192.3 303.1 430.3 679.3 1068 1545 2495 3593
5500 54.17 123.2 213.4 336.4 477.4 753.8 1186 1715 2769 3987
6000 59.62 135.6 234.9 370.2 525.5 829.7 1305 1887 3048 4389
6500 65.17 148.3 256.8 404.7 574.5 907.0 1427 2063 3332 4798
7000 70.82 161.1 279.0 439.8 624.3 985.6 1550 2242 3621 5214
7500 76.56 174.2 301.6 475.4 674.8 1065 1676 2424 3914 5636
8000 82.38 187.4 324.6 511.6 726.2 1146 1803 2608 4212 6065
8500 88.28 200.9 347.8 548.2 778.2 1229 1932 2795 4513 6499
9000 94.25 214.4 371.3 585.3 830.8 1312 2063 2984 4818 6939
9500 100.28 228.1 395.1 622.7 883.9 1396 2195 3175 5127 7382
10000 106.36 242.0 419.0 660.4 937.5 1480 2328 3367 5437 7830
