3410 Series Gas Ultrasonic Meters Operations Manual Section 5: Calibrate and configure the meter
3-9000-777 Rev E January 2018
Configure the Local Display 83
Display Items and display units
Display units - Meter volume units displayed are either U.S. Customary or Metric. The
Meter volume units displayed reflect the meter’s units selected on the
File|Program
Settings
dialog (e.g. U.S. Customary or Metric units). Configure the Meter volume units for
U.S. Customary selections:
• Cubic feet
• Thousand cubic feet
Or,
Metric unit selections are:
• Cubic meters
• Thousand cubic meters
Configure the
Flow rate time units:
• Second
• Hour
• Day
Display units preceded by a plus or minus sign indicate forward and reverse flow
direction, as shown in the table below.
Table 5-16 Local display labels, descriptions and valid units
Local display labels, descriptions and valid units
QFLOW — Uncorrected volume flow rate
• ACF – Actual Cubic Feet
• ACM – Actual Cubic Meters
• MACF – Thousand Actual Cubic Feet
• MACM –Thousand Actual Cubic Meters
TDYVL — Current day’s forward uncorrected volume
• +ACF – Actual Cubic Feet
• +ACM – Actual Cubic Meters
• +MACF – Thousand Actual Cubic Feet
• +MACM –Thousand Actual Cubic Meters
TDYVL — Current day’s reverse uncorrected volume
• -ACF – Actual Cubic Feet
• -ACM – Actual Cubic Meters
• -MACF – Thousand Actual Cubic Feet
• -MACM –Thousand Actual Cubic Meters
YSTVL — Previous day’s forward uncorrected volume
• +ACF – Actual Cubic Feet
• +ACM – Actual Cubic Meters
• +MACF – Thousand Actual Cubic Feet
• +MACM –Thousand Actual Cubic Meters
YSTVL — Previous day’s reverse uncorrected volume
• -ACF – Actual Cubic Feet
• -ACM – Actual Cubic Meters
• -MACF – Thousand Actual Cubic Feet
