3410 Series Gas Ultrasonic Meters Operations Manual Section 7: Tools commands
3-9000-777 Rev D June 2016
Navigate the waveform viewer 129
• Other keyboard commands - use the keyboard commands as a shortcut to access
the desired function.
Right-click the mouse over the chart to display these
commands or enter the keyboard command (Table 7-1).
Table 7-1 Waveform chart keyboard commands
Function Keystroke Description
Save State Ctrl + Home Save the current zoom settings. These settings can be recalled
with the Restore State command. Any saved settings are lost once
the utility is closed.
Restore State Home Restores the last saved zoom settings.
Cursor to Nearest Point F8 Moves the cursor to the nearest point displayed
Toggle Coarse/Fine Cursor F4 Toggles the cursor between and fast and slow moving cursor. The
cursor is physically larger for the fast moving cursor.
Toggle Lines/Markers F9 Toggles off the lines connecting the collected data and forces on
the markers.
Toggle Mouse Position Tip Ctrl+F4 Turns on tool tip showing the coordinates at which the mouse
pointer in pointing
Toggle Nearest Point Tip Ctrl+F9 Turns on tool tip showing the coordinates of the nearest data point
to the mouse pointer
Print Ctrl+P Prints the displayed chart
Copy to clipboard Ctrl+C Copies the displayed chart to the Windows® clipboard as table
data
Paste from clipboard Ctrl+V Paste data from the Windows® clipboard to the chart utility. The
data must be in the appropriate format to correctly paste as a new
series to the chart. Copy data from the chart to a text file to see the
appropriate format.
Waveform Zoom Ctrl+I Turns on/off the zoom feature while in Waveform Read or Stream
to file mode
