Mechanical/Electrical Troubleshooting (continued)Table C-1:
Problem Solution(s)
Waveform contains an
excessive amount of
noise
Increase the StackSize until noise level decreases (settings can be 1
(none), 2, 4, 8, or 16). If increasing the StackSize is not successful, try
turning on the filter or consult with Flow Lifecycle Services for Daniel
products if you are unsure of how stacking a signal can effect the meter's
operation. Refer to Technical Support under the Help menu of Daniel Me-
terLink for contact information.
Connected communi-
cation line to the flow
computer but no sig-
nal is received
• Check for loose connections at the flow meter and the flow computer
(see ).
• Check the CPU Module, Field Connection board and the Power Supply
wiring. Make sure the terminal block wiring and connectors are mak-
ing good contact.
Communicating with
meter but all chords
display failures
• Verify that the resistance of transducers is within Specification (1-2
Ω).
• Check the Acquisition board.
• Check the interconnect cables between the base enclosure and the
transmitter enclosure.
Chord is not indicating • Check the resistance of the failed transducer.
• If Chord A is not indicating, change the transducer cables from Chord
D to chord A
• If Chord D then fails, the transducers are bad on Chord A.
• The same test procedure can be accomplished by swapping Chords B
and C if a chord fails in either chord.
Note
Note that the outside chord cables cannot be exchanged with inner
chord cables.
Troubleshooting comm., mech., and elec.
