Data points for Polynomial wet calibration (continued)Table 5-4:
Daniel Meterlink
Display Name Data points, options and guidelines
Forward C1 Data points affected
FwdC
1 Options:
Enter a value (dimensionless) within the range [0.95, 1.05].
Forward C2 Data points affected
FwdC
2 Options:
Enter a value (s/m or s/ft ) within the range [-0.1, 0.1 s/m].
Forward C3 Data points affected
FwdC
0 Options:
Enter a value (m/s or ft/s) within the range (s
2
/m
2
or s
2
/ft
2
) within
the range [-0.1, 0.1 s
2
/m
2
].
Reverse C0 Data points affected
RevC
0 Options:
Enter a value (m/s or ft/s) within the range [-1, 1 m/s].
Reverse C1 Data points affected
RevC
1 Options:
Enter a value (dimensionless) within the range [0.95, 1.05].
Reverse C2 Data points affected
RevC
2 Options:
Enter a value (m/s or ft/s) within the range [-0.1, 0.1 s/m].
Reverse C3 Data points affected
RevC
0 Options:
Enter a value (s
2
/m
2
or s
2
/ft
2
) within the range [-0.1, 0.1 s
2
/m
2
].
Procedure
1. Select Polynomial from the Calibration|Meter Factors menu.
2. Add the value for the forward and reverse coefficients.
3. Click Write to apply the parameters to the meter.
No wet calibration
If no wet calibration is selected, then the wet calibration gas flow velocity is equal to the
dry calibration gas flow velocity.
Configurations
Operations manual 45
