6. Enable the WRITE PROT. switch on the CPU Module to write-protect the
configuration.
Calibrate analog inputs and outputsTable 5-6:
Daniel
MeterLink
Display name Dat Points, options and guidelines
Current output
Output setting
Data points affected:
• AO1 estModeOutputPercent
Options:
• Enter the integer percentage of full scale for the analog output
within the range [0, 100 %] where 0% corresponds to the mini-
mum output (4 mA) and 100% corresponds to the maximum
output (20 mA).
Guidelines
• The specified test value takes effect within one batch period of
clicking the Start button.
Current output
Start (Stop) AO1
Data points affected:
• IsAO1EnableTest
Options:
• Click on the StartAO1 button to enter the test mode (TRUE)
(Note: the Start button will become the Stop button after click-
ing on it.)
• Click on the StopAO1 button to exit the test mode (FALSE)
(Note: the Stop button will become the Start button after click-
ing on it.)
Guidelines
• The specified test value takes effect within one batch period of
clicking the Start button (see below).
Current output
Output setting
Data points affected:
• AO2TestModeOutputPercent
Options:
• Enter the integer percentage of full scale for the analog output
within the range [0, 100 %] where 0% corresponds to the mini-
mum output (4 mA) and 100% corresponds to the maximum
output (20 mA).
Guidelines
• The specified test value takes effect within one batch period of
clicking the Start button.
Note
The AO2 is only available with CPU module, part number
1-360-03-010.
Configurations
