24 • iPro Case Controller I&O Manual FM V1.01 026-1738 Rev 1
9.2. IPX106D Analog Outputs
The IPX expansion module has (three) 3 additional analog outputs available that can be used with the case controller if needed.
The outputs are located on terminals 20-23. Note that the IPX AO do not require dedicated 24VAC power like iPro analog outputs.
ANALOG OUTPUTS
TYPE: Non opto-insulated internal power
NUMBER OF OUTPUTS: 3
TYPE OF OUTPUT: 3 fixed outputs 0-10VDC (Out1 - Out3)
MAXIMUM LOAD: 40mA (Out1 - Out3)
22Ω per live analog output
NOTES: The electrical devices controlled by these analog outputs must be
powered separately with another transformer (do not use the same
secondary of the controller's power) in order to prevent the outputs
from malfunctioning or being damaged.
Table 9-2 - IPX Digital Output Specifications
