Emerson iPro - E2 E BACnet Network Settings Configuration

I/O Configuration Using the Visograph • 47
DischargeAir1
Case temperature sensor 1
iPro, IPX, or EXV20D
DischargeAir2
Case temperature sensor 2
DischargeAir3
Case temperature sensor 3
DischargeAir4
Case temperature sensor 4
DischargeAir5
Case temperature sensor 5
DischargeAir6
Case temperature sensor 6
DefrTerm1
Defrost cycle termination temperature sensor 1
DefrTerm2
Defrost cycle termination temperature sensor 2
DefrTerm3
Defrost cycle termination temperature sensor 3
DefrTerm4
Defrost cycle termination temperature sensor 4
DefrTerm5
Defrost cycle termination temperature sensor 5
DefrTerm6
Defrost cycle termination temperature sensor 6
Return1
Case return air temperature sensor 1
Return2
Case return air temperature sensor 2
Return3
Case return air temperature sensor 3
Pressure1
Evaporator suction pressure transducer 1
Pressure2
Evaporator suction pressure transducer 2
Pressure3
Evaporator suction pressure transducer 3
CoilOut1
CoilOut1
CoilOut2
CoilOut2
CoilOut3
CoilOut3
Table 14-1 - Analog Input Options
