Emerson Mentor MP Short Guide

Mentor MP Short Form Guide 25
Issue Number: 5 www.controltechniques.com
Safety Information Product information
Mechanical
installation
Electrical
installation
Getting started Running the motor
SMARTCARD
operation
Advanced
parameters
Diagnostics UL listing
Figure 3-10 Overall size 2B dimensions without terminal shrouds attached
495mm (19.49in)
453mm (17.84in)
149mm (5.87in)
140mm (5.51in)
140mm (5.51in)
66mm (2.60in)
30mm
(1.18in)
30mm
(1.18in)
30mm
(1.18in)
53mm
(2.09in)
38mm
(1.50in)
77mm
(3.03in)
90mm
(3.54in)
40mm
(1.58in)
40mm
(1.58in)
302mm
(11.89in)
8mm
(0.32in)
126mm (4.96in)
141mm (5.55in)
8mm
(0.32in)
472mm (18.58)
68mm
(2.68in)
126mm
(4.96in)
11.5mm (0.45in)
495mm (19.49in)
80mm
(3.15in)
80mm
(3.15in)
65mm
(2.56in)
8 holes to
suit M8
With the SMARTCARD installed to the drive, the depth measurement increases by 7.6
mm (0.30 in).
NOTE
