24 Mentor MP Short Form Guide
www.controltechniques.com Issue Number: 5
Figure 3-8 Overall size 2A / 2B dimensions with terminal shrouds attached
Figure 3-9 Overall size 2A dimensions without terminal shrouds attached
453mm (17.84in)
495mm (19.49in)
640mm
(25.20in)
85mm
(3.35in)
301mm (11.85in)
472mm (18.58)
68mm
(2.68in)
126mm
(4.96in)
11.5mm (0.45in)
495mm (19.49in)
80mm
(3.15in)
80mm
(3.15in)
65mm
(2.56in)
8 holes to
suit M8
302mm
(11.89in)
93mm
(3.66in)
495mm (19.49in)
453mm (17.84in)
149mm (5.87in)
140mm (5.51in)
140mm (5.51in)
66mm (2.60in)
30mm
(1.18in)
30mm
(1.18in)
30mm
(1.18in)
15mm
(0.59in)
11mm
(0.43in)
25mm
(0.98in)
25mm
(0.98in)
77mm
(3.03in)
90mm
(3.54in)
5mm
(0.20in)
126mm
(4.96in)
5mm
(0.20in)
141mm (5.55in)
472mm (18.58 in)
68mm
(2.68in)
126mm
(4.96in)
11.5mm (0.45in)
495mm (19.49in)
80mm
(3.15in)
80mm
(3.15in)
65mm
(2.56in)
8 holes to
suit M8
302mm
(11.89in)
With the SMARTCARD installed to the drive, the depth measurement increases by 7.6
mm (0.30 in).
NOTE
