Emerson Rosemount 8800D Series Reference Manual

Product Certifications
March 2016
Reference Manual
00809-0100-4772, Rev FA
134
Product Certifications
B.5.1 North American certifications
Factory Mutual (FM)
E5 Explosion proof-Intrinsically Safe for Class I, Division 1,
Groups B, C, and D;
Dust-ignition proof for Class II/III, Division 1, Groups E,
F, and G;
Temperature Code T6 (-50 °C ≤ Ta ≤ 70 °C)
Factory Sealed
Enclosure Type 4X, IP66
I5 Intrinsically safe for use in Class I, II, III Division 1,
Groups A, B, C, D, E, F, and G;
Non-incendive for Class I, Division 2, Groups A, B, C,
and D
NIFW (Non-incendive Field Wiring) when installed per
Rosemount Drawing 08800-0116
Temperature Code T4 (-50 °C ≤ Ta ≤ 70 °C) 4-20 mA
HART
®
Temperature Code T4 (-50 °C ≤ Ta ≤ 60 °C) Fieldbus
Enclosure Type 4X, IP66
IE FISCO for Class I, II, III, Division 1, Groups A, B, C, D, E,
F and G;
FNICO for Class I Division 2, Groups A, B, C, and D
when installed per Rosemount control drawing
08800-0116
Temperature Code T4 (-50 °C ≤ Ta ≤ 60 °C)
Enclosure Type 4X, IP66
Combined Factory Mutual (FM) certifications
K5 E5 and I5 Combination
Special conditions for safe use (X):
1. When fitted with 90V transient suppressors (T1
Option), the equipment is not capable of passing the
500V insulation test. This must be taken into account
upon installation.
2. The Rosemount 8800D Vortex Flowmeter when
ordered with aluminum electronics housing is
considered to constitute a potential risk of ignition by
impact or friction. Care should be taken into account
during installation and use to prevent impact or
friction.
Canadian Standards Association (CSA)
E6 Explosion-Proof for Class I, Division 1, Groups B, C,
and D;
Dust-ignition proof for Class II and Class III, Division 1,
Groups E, F, and G
Class I, Zone 1, Ex d[ia] IIC
Temperature Code T6 (-50 °C ≤ Ta ≤ 70 °C)
Factory Sealed
Single Seal
Enclosure Type 4X
I6 Intrinsically safe for use in Class I, II, III Division 1,
Groups A, B, C, D, E, F, G;
Non-incendive for Class I, Division 2, Groups A, B, C
and D
Temperature Code T4 (-50 °C ≤ Ta ≤ 70 °C) 4-20 mA
HART
Temperature Code T4 (-50 °C ≤ Ta ≤ 60 °C) Fieldbus
Single Seal
Enclosure Type 4X
IF FISCO for Class I, Division 1, Groups A, B, C, and D
FNICO for Class I Division 2, Groups A, B, C, and D
Temperature Code T4 (-50 °C ≤ Ta ≤ 60 °C)
When installed per Rosemount drawing 08800-0112
Enclosure Type 4X
Combined Canadian certifications (CSA)
K6 E6 and I6 Combination
Combined North America certifications (FM and CSA)
KB E5, I5, E6, and I6 Combination
B.5.2 European certifications
ATEX Intrinsic Safety
EN 60079-0: 2012
EN 60079-11: 2012
I1 Certification No. Baseefa05ATEX0084X
ATEX Marking
II 1 G Ex ia IIC T4 Ga (-60 °C ≤ Ta ≤ 70 °C) 4-20 mA
HART
II 1 G Ex ia IIC T4 Ga (-60 °C ≤ Ta ≤ 60 °C) Fieldbus
0575
ATEX FISCO
IA Certification No. Baseefa05ATEX0084X
ATEX Marking
II 1 G Ex ia IIC T4 Ga (-60 °C ≤ Ta ≤ 60 °C)
0575
Special conditions for safe use (X):
1. When fitted with 90V transient suppressors (T1
option), the equipment is not capable of passing the
500V isolation test. This must be taken into account
upon installation.
4-20 mA HART
entity parameters
Fieldbus entity
parameters
FISCO input
parameters
U
i
= 30 VDC U
i
= 30 VDC U
i
= 17.5 VDC
I
i
(1)
1. Total for transmitter.
= 185 mA I
i
(1)
= 300 mA I
i
(1)
= 380 mA
P
i
(1)
= 1.0 W P
i
(1)
= 1.3 W P
i
(1)
= 5.32 W
C
i
= 0 μF C
i
= 0 μF C
i
= 0 μF
L
i
= 0.97mH L
i
< 10 μH L
i
< 10 μH
