Product Certifications
March 2016
Reference Manual
00809-0100-4772, Rev FA
136
Product Certifications
FISCO
IG Certificate: IECEx BAS 05.0028X
Ex ia IIC T4 Ga (-60 °C ≤ Ta ≤ 60 °C)
Special conditions for safe use (X):
1. When fitted with 90V transient suppressors (T1
Option), the equipment is not capable of passing the
500V isolation test. This must be taken into account
upon installation.
2. The enclosure may be made from aluminum alloy and
given a protective polyurethane paint finish; however,
care should be taken to protect it from impact or
abrasion when located in Zone 0 environment. The
polyurethane paint finish may constitute an
electrostatic hazard and must only be cleaned with a
damp cloth.
3. When the equipment is installed, particular
precautions must be taken to ensure, taking into
account the effect of process fluid temperature, that
the ambient temperature of the electrical housing of
the equipment meets the marked protection type
temperature range.
Type n certification
IEC 60079-0: 2011
IEC 60079-11: 2011
IEC 60079-15: 2010
N7 Certificate No. IECEx BAS05.0029X
Ex nA ic IIC T5 Gc (-50 °C ≤ Ta ≤ 70 °C) 4-20 mA HART
Ex nA ic IIC T5 Gc (-50 °C ≤ Ta ≤ 60 °C) Fieldbus
Maximum Working Voltage = 42 VDC 4-20 mA HART
Maximum Working Voltage = 32 VDC Fieldbus
Special conditions for safe use (X):
1. When fitted with 90V transient suppressors (T1
Option), the equipment is not capable of passing the
500V isolation test. This must be taken into account
upon installation.
2. The enclosure may be made from aluminum alloy
with a protective polyurethane paint finish. The
polyurethane paint finish may constitute an
electrostatic hazard and must only be cleaned with a
damp cloth.
3. When the equipment is installed, particular
precautions must be taken to ensure, taking into
account the effect of process fluid temperature, that
the ambient temperature of the electrical housing of
the equipment meets the marked protection type
temperature range.
Flameproof certification
IEC 60079-0: 2007-10
IEC 60079-1: 2007-04
IEC 60079-11: 2011
IEC 60079-26: 2006
E7 Certificate: IECEx KEM 05.0017X
Integral Flowmeter marked:
Ex d [ia] IIC T6 Ga/Gb (-50 °C ≤ Ta ≤ 70 °C)
Remote Transmitter marked:
Ex d [ia Ga] IIC T6 Gb (-50 °C ≤ Ta ≤ 70 °C)
with meter body marked:
Ex ia IIC T6 Ga (-50 °C ≤ Ta ≤ 70 °C)
42 VDC Max 4-20 mA HART
32 VDC Max Fieldbus
U
m
= 250V
Installation instructions:
1. The cable and conduit entry devices shall be of a
certified flameproof type Ex d, suitable for the
conditions of use and correctly installed.
2. Unused apertures shall be closed with suitable
blanking elements.
3. When the ambient temperature at the cable or
conduit entries exceed 60 °C, cables suitable for at
least 90 °C shall be used.
4. The remote mounted sensor may only be connected
to the transmitter with the associated cable, supplied
by the manufacturer.
Special conditions for safe use (X):
1. For information regarding the dimensions of the
flameproof joints, the manufacturer shall be
contacted.
2. The Flowmeter shall be provided with special
fasteners of property class A2-70 or A4-70.
3. Units marked with “Warning: Electrostatic Charging
Hazard” may use non-conductive paint thicker that
0.2 mm. Precaution shall be taken to avoid ignition
due to electrostatic charge on the enclosure.
Combined IECEx certifications
K7 E7, I7, and N7 Combination
P
i
(1)
= 1.0 W P
i
(1)
= 1.3 W P
i
(1)
= 5.32 W
C
i
= 0 μF C
i
= 0 μF C
i
= 0 μF
L
i
= 0.97mH L
i
< 10 μH L
i
< 10 μH
1. Total for transmitter.
4-20 mA HART
entity parameters
Fieldbus entity
parameters
FISCO input
parameters
