CG Drives & Automation 01-7491-01r0 Functional description 115
Process Data Mode [2632]
Enter the mode of process data (cyclic data). For further
information, see the Fieldbus option manual.
Read/Write [2633]
Select read/write to control the inverter over a Fieldbus
network. For further information, see the Fieldbus option
manual.
Additional Process Values [2634]
Define the number of additional process values sent in cyclic
messages.
CANBaudrate [2635]
Set the baud rate for CANopen Fieldbus.
* Under normal traffic conditions, i.e. with cyclic bus traffic
above 2 Hz, the baudrate should be detected within
5seconds.
NOTE: For CANopen module this menu is forced to
“8”.
2632 PrData Mode
Default: Basic
None 0 Control/status information is not used.
Basic 4
4 byte process data control/status
information is used.
Extended 8
4 byte process data (same as Basic
setting) + additional proprietary protocol
for advanced users is used.
2633 Read/Write
Default: RW
RW 0
Read 1
Valid for process data. Select R (read only) for logging
process without writing process data. Select RW in normal
cases to control inverter.
NOTE: For CANopen module this menu is forced to
“Basic”.
2634 AddPrValues
Default: 0
Range: 0-8
NOTE: Used for CANopen module only
2635 CANBaudrate
Default: 8
0 10 kbps
1 20 kbps
2 50 kbps
3Reserve
4 100 kbps
5 125 kbps
6 250 kbps
7 500 kbps
8 1 Mbps
9 Auto *
NOTE: The automatic baud rate detection will NOT
work if there is no traffic on the network.
