1.7 Glossary
1.7.1 Abbreviations and symbols
In this manual the following abbreviations are used:
1.7.2 Definitions
In this manual the following definitions for current, torque
and frequency are used:
Table 3 Abbreviations
Abbreviation/
symbol
Description
DSP Digital signals processor
AC drive Frequency converter
PEBB Power Electronic Building Block
IGBT Insulated Gate Bipolar Transistor
CP
Control panel, the programming and
presentation unit on the AC drive
HCP Handheld control panel (option)
EInt Communication format
UInt Communication format (Unsigned integer)
Int Communication format (Integer)
Long Communication format
SELV Safety Extra Low Voltage
The function cannot be changed in run
mode
Table 4 Definitions
Name Description Quantity
I
IN
Nominal input current of AC drive A
RMS
I
NOM
Nominal output current of AC drive A
RMS
I
MOT
Nominal motor current A
RMS
P
NOM
Nominal power of AC drive kW
P
MOT
Motor power kW
T
NOM
Nominal torque of motor Nm
T
MOT
Motor torque Nm
f
OUT
Output frequency of AC drive Hz
f
MOT
Nominal frequency of motor Hz
n
MOT
Nominal speed of motor rpm
I
CL
Maximum output current A
RMS
Speed Actual motor speed rpm
Torque Actual motor torque Nm
Sync
speed
Synchronous speed of the motor rpm
