Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Technical Data 225
14.7.2 Fuses according to NEMA
ratings
Table 67 Types and fuses
Model
FDU
Input
current
[Arms]
Mains input fuses
UL
Class J TD
(A)
Ferraz-
Shawmut
type
48-003 2.2 6 AJT6
48-004 3.5 6 AJT6
48-006 5.2 6 AJT6
48-008 6.9 10 AJT10
48-010 8.7 10 AJT10
48-013 11.3 15 AJT15
48-018 15.6 20 AJT20
48-025 21.7 25 AJT25
48-026 22 25 AJT25
48-030 26 30 AJT30
48-031 26 30 AJT30
48-036 31 35 AJT35
48-037 31 35 AJT35
48-045 39 45 AJT45
48-046 40 45 AJT45
48-058 50 60 AJT60
48-061 52 60 AJT60
48-072 64 80 AJT80
48-074 65 80 AJT80
48-088 78 100 AJT100
48-090 78 100 AJT100
48-105 91 110 AJT110
48-109 94 110 AJT110
48-142 126 125 AJT150
48-146 126 150 AJT150
48-171 152 175 AJT175
48-175 152 175 AJT175
48-205 178 200 AJT200
48-210 182 200 AJT200
48-228 197 250 AJT250
48-244 211 250 AJT250
48-250 216 250 AJT250
48-293 254 300 AJT300
48-295 256 300 AJT300
48-300 260 300 AJT300
48-365 324 350 AJT350
48-375 324 350 AJT350
48-430 372 400 AJT400
48-500 432 500 AJT500
48-600 520 600 AJT600
48-650 562 600 AJT600
48-720 648 700 A4BQ700
48-750 648 700 A4BQ700
48-860 744 800 A4BQ800
48-900 795 800 A4BQ800
48-1K0 864 1000 A4BQ1000
48-1K15 996 1000 A4BQ1000
48-1K2 1037 1200 A4BQ1200
48-1K25 1037 1200 A4BQ1200
48-1K35 1170 1200 A4BQ1200
48-1K5 1296 1500 A4BQ1500
48-1K75 1516 1600 A4BQ1600
48-2K0 1732 1800 A4BQ1800
48-2K25 1949 2000 A4BQ2000
48-2K5 2165 2500 A4BQ2500
Table 67 Types and fuses
Model
FDU
Input
current
[Arms]
Mains input fuses
UL
Class J TD
(A)
Ferraz-
Shawmut
type
