11.7 View Operation/Status
[700]
Menu with parameters for viewing all actual operational
data, such as speed, torque, power, etc.
11.7.1 Operation [710]
Process Value [711]
The process value is showing the process actual value,
depending on selection done in chapter, Process Source
[321].
Speed [712]
Displays the actual shaft speed.
Torque [713]
Displays the actual shaft torque.
Shaft power [714]
Displays the actual shaft power. Negative sign is used when
the shaft is generating mechanical power to the motor.
Electrical Power [715]
Displays the actual electrical output power. Negative sign is
used when the motor is generating electrical power to the
drive unit.
Current [716]
Displays the actual output current.
Output Voltage [717]
Displays the actual output voltage.
Frequency [718]
Displays the actual output frequency.
DC Link Voltage [719]
Displays the actual DC link voltage.
IBGT Temperature [71A]
Displays the actual IGBT temperature, measured. The
signal is generated by a sensor in the IGBT module.
711 Process Val
Unit
Depends on selected Pocess source [321]
and Process Unit [322].
Resolution
Speed: 1 rpm, 4 digits
Other units: 3 digits
712 Speed
Unit: rpm
Resolution: 1 rpm, 4 digits
NOTE: If accessed via communication, the signal is
unreliable at speeds outside -32768 ... 32767.
713 Torque
Unit: %, Nm
Resolution: 1 %, 0.1 Nm
714 Shaft Power
Unit: W
Resolution: 1W
715 El Power
Unit: kW
Resolution: 1 W
716 Current
Unit: A
Resolution: 0.1 A
717 Output Volt
Unit: V
Resolution: 0.1 V
718 Frequency
Unit: Hz
Resolution: 0.1 Hz
719 DC Voltage
Unit: V
Resolution: 0.1 V
71A IGBT Temp
Unit: °C
Resolution: 0.1°C
