CG Drives & Automation 01-7491-01r0 171
11.6.2 Analogue Multiplexer [620]
The Analog Mux compares two configurable analogue input
signals (InA and InB) and generates a virtual analogue
output. Output behavior depends on the configured
operator. Output can be used as source for analogue output
or input value to analogue comparators.
Since both input and output is limited to range -100% to
100% some operations might overflow. Result is always
limited within the range. Consequently some operators have
a "divided by 2" variant to always produce overflow safe
variants (result is always within the range).
AnMux1 [621]
AnMux InA [6211]
First input to the AnMux1. Select one of AnIn1 - 4. Input
numbered as [6111], i.e. AnIn1 = 16 and default is AnIn1.
AnMux InB [6212]
Second input to AnMux1. Select one of AnIn1 - 4. Input
numbered as [6111], i.e. AnIn1 = 16 and default is AnIn2.
Operator [6213]
Operator of the Analogue Mux 1. The names shown on the
control panel will be changed according to the following.
AnMux2 [622]
The same function as in Analog Mux1[621].
AnMux InA [6221]
The function is the same as in Analogue Mux InA value
[6211].
AnMux InB [6222]
The function is the same as in Analogue Mux InB value
[6212].
Operator [6223]
The function is the same as in Operator [6213].
6211 AnMux InA
Default: Process Val
Selections: Same as in menu CA1 Value
[6111].
6212 AnMux InB
Default: Process Val
Selections: Same as in menu CA1 Value
[6112].
6213 Operator
Default: Off
Off 0 No output
MIN(A,B) 1 Minimal value of InA and InB
MAX(A,B) 2 Max value of InA and InB
A+B 3 Sum of InA and InB
(A+B)/2 4
Sum of InA and InB that is overflow
safe
A-B 5 Difference of InA and InB
(A-B)/2 6
Difference of InA and InB that is
overflow safe
B-A 7 Difference of InB and InA
(B-A)/2 8
Difference of InB and InA that is
overflow safe
ABS(A-B) 9
Absolute value of difference of InA
and InB.
ABS(A-B)/2 10
Absolute value of difference of InA
and InB that is overflow safe
6221 AnMux InA
Default: Process value
Selections: Same as in menu CA1 Value
[6111].
6222 AnMux InB
Default: Process value
Selections: Same as in menu CA1 Value [6112].
6223 Operator
Default: Off
Selections: Same as in menu Operator [6113].
