246 Menu List CG Drives & Automation 01-7491-01r0
710
Operation
[710]
711 Process Val 31001 121/145 23E9 1001 Long, 1=0.001 EInt
712 Speed 31002 121/146 23EA 1002 Int, 1=1rpm Int
713 Torque
31003 121/147 23EB 1003
Long,
1=0.1Nm
EInt
31004 121/148 23EC 1004 Long, 1=1% EInt
714 Shaft Power 31005 121/149 23ED 1005 Long, 1=1W EInt
715 El Power 31006 121/150 23EE 1006 Long, 1=1W EInt
716 Current 31007 121/151 23EF 1007 Long, 1=0.1A EInt
717 Output Volt 31008 121/152 23F0 1008 Long, 1=0.1V EInt
718 Frequency 31009 121/153 23F1 1009 Long, 1=0.1Hz EInt
719 DC Voltage 31010 121/154 23F2 1010 Long, 1=0.1V EInt
71A IGBT Temp 31011 121/155 23F3 1011 Long, 1=0.1°C EInt
71B PT100 1,2,3
31012 121/156 23F4 1012 Long, 1=1°C EInt
31013 121/157 23F5 1013 Long, 1=1°C EInt
31014 121/158 23F6 1014 Long, 1=1°C EInt
71C PT100 4,5,6
31097 121/241 2449 1097 Long, 1=1°C EInt
31098 121/242 244A 1098 Long, 1=1°C EInt
31099 121/243 244B 1099 Long, 1=1°C EInt
720 Status [720]
721 VSD Status 31015 121/159 23F7 1015 UInt UInt
722 Warning 31016 121/160 23F8 1016 UInt UInt
723 DigIn Status 31017 121/161 23F9 1017 UInt, 1=1 UInt
724 DigOutStatus 31018 121/162 23FA 1018 UInt, 1=1 UInt
725 AnIn 1 2
31019 121/163 23FB 1019 Long, 1=1% EInt
31020 121/164 23FC 1020 Long, 1=1% EInt
726 AnIn 3 4
31021 121/165 23FD 1021 Long, 1=1% EInt
31022 121/166 23FE 1022 Long, 1=1% EInt
727 AnOut 1 2
31023 121/167 23FF 1023 Long, 1=1% EInt
31024 121/168 2400 1024 Long, 1=1% EInt
728 IO Status B1 31025 121/169 2401 1025 UInt, 1=1 UInt
729 IO Status B2 31026 121/170 2402 1026 UInt, 1=1 UInt
72A IO Status B3 31027 121/171 2403 1027 UInt, 1=1 UInt
72B Area D Stat
72B1 Area D LSB 30180 118/89 20B4 180 UInt, 1=1 UInt
72B2 Area D MSB 30182 118/91 20B6 182 UInt, 1=1 UInt
72C VIO Status 30181 118/90 20B5 181 UInt, 1=1 UInt
730
Stored values
[730]
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
