Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Menu List 247
731 Run Time
31028 121/172 2404 1028 Long, 1=1h EInt
31029 121/173 2405 1029 Long, 1=1m EInt
31030 121/174 2406 1030 Long, 1=1s EInt
7311 Reset RunTm No 7 0/6 2007 7 UInt UInt
732 Mains Time hh:mm:ss
31031 121/175 2407 1031 Long, 1=1h EInt
31032 121/176 2408 1032 Long, 1=1m EInt
31033 121/177 2409 1033 Long, 1=1s EInt
733 Energy Wh 31034 121/178 240A 1034 Long, 1=1Wh EInt
7331 Rst Energy No 6 0/5 2006 6 UInt UInt
800
View Trip Log
[800]
810
Trip message
log [810]
31101 121/245 244D 1101 UInt, 1=1 UInt
811 Process Val 31102 121/246 244E 1102 Long, 1=0.001 EInt
812 Speed 31103 121/247 244F 1103 Int, 1=1rpm Int
813 Torque
31104 121/248 2450 1104
Long,
1=0.1Nm
EInt
31105 121/249 2451 1105 Long, 1=1% EInt
814 Shaft Power 31106 121/250 2452 1106 Long, 1=1W EInt
815 El Power 31107 121/251 2453 1107 Long, 1=1W EInt
816 Current 31108 121/252 2454 1108 Long, 1=0.1A EInt
817 Output volt 31109 121/253 2455 1109 Long, 1=0.1V EInt
818 Frequency 31110 121/254 2456 1110 Long, 1=0.1Hz EInt
819 DC Voltage 31111 122/0 2457 1111 Long, 1=0.1V EInt
81A IGBT Temp 31112 122/1 2458 1112 Long, 1=0.1°C EInt
81B PT100 1,2,3
31113 122/2 2459 1113 Long, 1=1°C EInt
31114 122/3 245A 1114 Long, 1=1°C EInt
31115 122/4 245B 1115 Long, 1=1°C EInt
81C VSD Status 31116 122/5 245C 1116 UInt UInt
81D DigIn Status 31117 122/6 245D 1117 UInt, 1=1 UInt
81E DigOutStatus 31118 122/7 245E 1118 UInt, 1=1 UInt
81F AnIn 1 2
31119 122/8 245F 1119 Long, 1=1% EInt
31120 122/9 2460 1120 Long, 1=1% EInt
81G AnIn 3 4
31121 122/10 2461 1121 Long, 1=1% EInt
31122 122/11 2462 1122 Long, 1=1% EInt
81H AnOut1 2
31123 122/12 2463 1123 Long, 1=1% EInt
31124 122/13 2464 1124 Long, 1=1% EInt
81I IO Status B1 31125 122/14 2465 1125 UInt, 1=1 UInt
81J IO Status B2 31126 122/15 2466 1126 UInt, 1=1 UInt
81K IO Status B3 31127 122/16 2467 1127 UInt, 1=1 UInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
